Description of the volumetric single color mixer,
The volumetric dosers color mixer are suitable for auto-proportional mixing of new material, regrind, master batch and additives. A brushless DC motor is used in this series. The microprocessor accurately controls rotation of the high precise dosing screws to squeeze out materials with an accuracy of 1% form set point. A gear motor with deceleration ratio of 30:1 or 100:1 is coupled to a dosing screw of six models with output ranging from 0.1~32kg/hr. Double color doser can be supplied to match with two single color doser if required by clients.



Features of the volumetric color mixer

Everlasting data memorizer and settings storage.
Use brushless DC motor and free from maintenance.
Microprocessor control, intelligent and accurate in calculation.
External signals can be directly interfaced with the control box.
Dosing screws are chrome plated for durability.
Unit is comprised of standard modules for ease of cleaning, disassembly and interchangeability.
Three-tubes hopper magnet is equipped at the base of the single color doser to absorb metal impurities so to prevent the screw of molding machine from damage.
Single color doser takes base blender as an option to make blending more evenly.
Blender built-in a standard accessory for double color doser and it can meet client's need for double blending.
Main material hopper is a standard accessory for double color mixer. It is optional for single color mixer.



Specification of the volumetric color mixer,



Note:1) “ * ” means the output capacity depends on model selected, data of the single color mixer/doser can be a reference. For example: RS-TCM-D-38-16/38-14,output capacity l .7-52kg/hr.
2) “ ** ” stands for external dia. of screw is up to model selected.
3) Single-color volumetric mixer adds to mixer, add “MS” at the back of the model.
4) AII output capacity from above models are base on data from density 1.2,dia. 2-3 mm master batch in a test criteria of continuous running.

5), Voltage:1⊙,220V,50Hz.

Machine color--- blue or white, or others OEM;

Machine brand--- factory brand, OEM brand or no brand;

We do OEM!

We do B2B, B2C!

For more details of the volumetric color mixers, please contact us for E-sheets!

For more choice of mixers, plastic machinery products, please contact us for E-catalogue and Price Lists!

If there are any questions on plastic machines, please feel free to contact us.

We can provide all kinds of plastics machinery solutions to meet your special demands accordingly at one-stop purchasing!
