Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor

High Cutting Precision With Servo Motor For X Y Digital Label Die Cutter

Hightlights

• Tungsten steel rotary baldes technology
• High cutting precision with servo motor for X Y
• Fully automatic tension and feeding control
• Roll to roll or roll to cut die cutting
• The slitting speed up to 60m per minute
• Two rewinders are standard
• Cutting speed is up to 6m/m

​Key specifications

Technology Tungsten stell rotary blade Cut speed 6m per minute (10*10cm)

Label width 10-310mm

Media width 100-330mm

Cut precision 0.1mm (duplicate) Media thickness 60-400um

Max. roll diameter 450mm

Machine dimension 1600*1000*1360mm

Machine weight Approx. 560kgs

Power supply 220-240V 1100W

Machine features

2 cutting head Standard (Max. 4 cutting head)

4 slitter unit Standard (Max. 15 slitter) Inline web guide Standard

lamination Standard film liner removal option

waste removal Standard

up rewinder Standard down rewinder Standard

sheet cutter option

Machine
